JCB
Komatsu
PW95-1
Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 33,303 lb |
|---|---|
| Fuel Capacity | 63.5 gal |
| Hydraulic Pump Flow Capacity | 73.0 gal/min |
| Hydraulic System Fluid Capacity | 32.8 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 3.9 gal |
| Cooling System Fluid Capacity | 4.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | load-sensed hydraulic system with twin variable flow piston pumps roviding flow on demand for maximum efficiency |
| Tire Size | twins: 10x20 16PR single: 18R19.5 (Radials) |
| Oscillating Axle Angle | 17 ° |
| Front Diff Fluid Capacity | 3.7 gal |
| Rear Diff Fluid Capacity | 3.2 gal |
Engine
| Engine Model | JCB EcoMAX 444 TCA EU Stage IV EPA Tier 4 Final compliant |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 109.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Type | 4-stroke 4-cyclinder in-line common rail direct injection turbo charged and intercooled diesel |
| Alternator | 55 A |
| Cooling system | Large capacity radiator |
| Rated Power | 125.0 hp |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 121 in |
| Upper Structure Clearance | 50 in |
| Overall Width - Outriggers Down | 98 in |
Transmission
| Max Travel Speed | 15.6 mph |
|---|---|
| Transmission Type | hydrostatic powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 214 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Reach Along Ground | 333 in |
| Max Loading Height | 253 in |
| Shipping Length of Unit | 322 in |
| Shipping Height of Unit | 109 in |
| Max Vertical Wall Dig Depth | 178 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 231 in |
|---|---|
| Max Cutting Height | 379 in |
| Max Reach Along Ground | 350 in |
| Max Loading Height | 268 in |
| Shipping Height of Unit | 109 in |
| Shipping Length of Unit | 320 in |
| Max Vertical Wall Dig Depth | 199 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 246 in |
|---|---|
| Max Cutting Height | 395 in |
| Max Reach Along Ground | 366 in |
| Max Loading Height | 282 in |
| Shipping Height of Unit | 128 in |
| Shipping Length of Unit | 328 in |
| Max Vertical Wall Dig Depth | 222 in |
