JCBJCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
13 data points
Operating Specifications
| Operating Weight | 57,818 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 89.6 gal/min |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
Engine
| Engine Model | BB-6BGIT |
|---|---|
| Displacement | 396 in³ |
| Net Power | 161.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 127 in |
| Length of Track on Ground | 151 in |
| Tail Swing Radius | 121 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Shoe Size | 24 in |
|---|
