JCB

VM166PD

Padfoot Compactor

Operating Weight
37,038 lb
Max Speed
7.1 mph
Drum Width
83 in
Gross Power
173.0 hp
All padfoot compactors
JCB VM166PD Padfoot Compactor
1 / 5
Image 1 of 5
Image: machinerytrader.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight37,038 lb
Max Speed7.1 mph
Fuel Capacity105.7 gal
Hydraulic System Fluid Capacity21.2 gal
Operating Voltage12 V
Engine Oil Capacity3.9 gal
Alternator Supplied Amperage95 A
Cooling System Fluid Capacity5.1 gal

Engine

Engine specifications
Engine ModelB5.9
Displacement359 in³
Power Measured @2,200 rpm
Gross Power173.0 hp

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab117 in
Wheelbase10 in
Width Over Tires90 in
Overall Length w/o Blade230 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1-26/8PR

Drum

Drum specifications
Drum Width83 in
Vibration Frequency 129 vpm
Centrifugal Force - High46,760 lb
Drum Diameter63 in
Nominal Amplitude - High0 in
Pad Height4 in
Number of Pads132
Centrifugal Force - Low72,164 lb
Nominal Amplitude - Low0 in
Vibratory Frequency 235 vpm
