JCB

VMT500

Smooth Drum Roller

Operating Weight
10,693 lb
Max Speed
6.8 mph
Drum Width
55 in
Gross Power
46.6 hp
All smooth drum rollers
JCB VMT500 Smooth Drum Roller
1 / 5
Image 1 of 5
Image: mkplant.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight10,693 lb
Max Speed6.8 mph
Fuel Capacity20.1 gal
Operating Voltage12 V
Hydraulic System Fluid Capacity13.3 gal
Engine Oil Capacity2.6 gal
Alternator Supplied Amperage45 A

Engine

Engine specifications
Engine ModelV 2203
Displacement134 in³
Power Measured @2,800 rpm
Gross Power46.6 hp
Number of Cylinders4

Dimensions

Dimensions specifications
Ground Clearance12 in
Height - Top of Cab101 in
Wheelbase7 in
Overall Length9 in

Drum

Drum specifications
Drum Width55 in
Drum Diameter32 in
Vibration Frequency 150 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High7,419 lb
Vibration Frequency 255 vpm
Static Linear Load8 lb-ft
