John Deere
Wacker Neuson
803 DUAL POWER
Mini Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 4,173 lb |
|---|---|
| Fuel Capacity | 5.2 gal |
| Hydraulic Pump Flow Capacity | 13.5 gal/min |
| Hydraulic System Fluid Capacity | 5.3 gal |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 0.9 gal |
| Cooling System Fluid Capacity | 0.8 gal |
Engine
| Engine Model | 3TNV70 |
|---|---|
| Displacement | 52 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 14.8 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 95 in |
| Length of Track on Ground | 48 in |
| Tail Swing Radius | 28 in |
| Width to Outside of Tracks | 50 in |
| Removal Counterweight Clearance | 18 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 42 in |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 86 in |
|---|---|
| Max Reach Along Ground | 154 in |
| Max Loading Height | 101 in |
| Shipping Length of Unit | 142 in |
| Max Cutting Height | 141 in |
| Shipping Height of Unit | 95 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 94 in |
|---|---|
| Max Cutting Height | 145 in |
| Max Loading Height | 104 in |
| Shipping Height of Unit | 95 in |
| Shipping Length of Unit | 144 in |
