John Deere
JCB
210S
Backhoe Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Operating Weight 4wd | 16,960 lb |
|---|---|
| Operating Weight 2wd | 14,429 lb |
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 24.0 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 12PR/12.5/80-18 10PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Alternator Supplied Amperage | 90 A |
| Transmission Fluid Capacity | 4.0 gal |
| Rear Axle Fluid Capacity | 4.8 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 92.0 hp |
| Aspiration | Turbocharged |
| Net Max Torque | 282 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 36.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | tandem gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 86 in |
| Transport Length | 282 in |
| Height to Top of Suspended Cab | 110 in |
Transmission
| Max Speed | 23.2 mph |
|---|---|
| Max Speed - Reverse | 13.4 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 19.5L-24 10PR |
|---|
General Specifications
| Operating Weight lbs (kg) | 14,430 (6,545) Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.5 (4.5) Starting 2009 Model Year |
| Lift Capacity lbs (kgs) | 7,340 (3,329) Starting 2007 Model Year |
| Loading Height ft (m) | 11.2 (3.41) Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | 22.4 (36) Starting 2007 Model Year |
| Backhoe Loading Height ft. (m) | 11.2 (3.4) Starting 2009 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 22.4 (36) Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 10,300 (4,672) Starting 2007 Model Year |
| Digging Depth ft (m) | 14.5 (4.5) Starting 2007 Model Year |
| Loader SAE HP (kw) | 92 (68) Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 7,340 (3,329) Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 10,300 (4,672) Starting 2009 Model Year |
| SAE Net hp (kW) | 92 (68) Starting 2007 Model Year |
| SAE HP (KW) | 92 (68) Starting 2010 Model Year |
| Weight lbs (kg) | 14,430 (6,545) Starting 2010 Model Year |
Backhoe
| Dig Depth | 174 in |
|---|---|
| Reach From Swivel | 220 in |
| Dig Depth - Extended | 222 in |
| Load Height - Extended | 169 in |
| Bucket Dig Force | 11,990 lb |
| Reach From Swivel - Extended | 264 in |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Lift Capacity | 7,340 lb |
| Clearance at Max Dump Height | 107 in |
| Bucket Breakout Force | 11,151 lb |
| Bucket Width | 86 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 6 in |
