John Deere
Case
1825B
Skid Steer Loader
33 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 5,150 lb |
|---|---|
| Max Speed | 6.8 mph |
| Fuel Capacity | 17.5 gal |
| Hydraulic System Fluid Capacity | 5.1 gal |
| Tire Size | 10x16.5 8 PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 A |
| Engine Oil Fluid Capacity | 2.4 gal |
| Cooling System Fluid Capacity | 1.7 gal |
| Chain Box Fluid Capacity - each side | 4.0 gal |
Engine
| Engine Model | 4024T |
|---|---|
| Displacement | 149 in³ |
| Power Measured @ | 2,400 rpm |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 15.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,450 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 39 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 18 in |
| Length with Bucket | 125 in |
| Clearance at Max Lift and Dump | 84 in |
| Turning Radius from Center - inc bucket | 75 in |
| Length w/o Bucket | 97 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 1,261 lb |
| Tipping Angle | 2,527 ° |
| Operating Width | 59 in |
| Breakout Force | 3,303 psi |
