Komatsu
Caterpillar
252
Skid Steer Loader
54 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 3,417 lb |
|---|---|
| Max Speed | 5.6 mph |
| Fuel Capacity | 7.2 gal |
| Hydraulic System Fluid Capacity | 3.2 gal |
| Tire Size | 27/8.50x15 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Fluid Capacity | 0.9 gal |
Engine
| Engine Model | 3D74E-1FC |
|---|---|
| Displacement | 61 in³ |
| Power Measured @ | 2,800 rpm |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.7 gal/min |
|---|---|
| Relief Valve Pressure | 1,596 psi |
| Pump Type | gear pump |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 74 in |
| Wheelbase | 30 in |
| Width Over Tires | 41 in |
| Reach at Max Lift and Dump | 15 in |
| Length with Bucket | 102 in |
| Clearance at Max Lift and Dump | 77 in |
| Turning Radius from Center - inc bucket | 58 in |
| Turning Radius from Center - machine rear | 50 in |
Loader
| Bucket Capacity | 0.10 yd³ |
|---|---|
| Operating Load Rating | 860 lb |
| Tipping Angle | 1,720 ° |
| Breakout Force | 2,255 psi |
