John Deere
Ingersoll Rand
BL370
Backhoe Loader
30 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Fuel Capacity | 36.1 gal |
|---|---|
| Hydraulic System Fluid Capacity | 24.0 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 11L-15 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 65 A |
| Max Weight | 14,698 lb |
| Rear Axle Fluid Capacity | 3.5 gal |
| Front Axle Fluid Capacity | 2.3 gal |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 92.5 hp |
| Net Power | 86.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Make | John Deere |
| Stroke | 5 in |
| Bore | 4 in |
Hydraulic System
| Pump Flow Capacity | 36.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Open center |
Dimensions
| Wheelbase | 83 in |
|---|---|
| Transport Width | 94 in |
| Transport Length | 207 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 20.6 mph |
|---|---|
| Max Speed - Reverse | 20.6 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Synchronized |
Tires & Wheels
| Rear Tires Size | 16.9-28 |
|---|
General Specifications
| Operating Weight lbs (kg) | 14,700 (6,670) — Starting 2004 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 7,200 (3,266) — Starting 2004 Model Year |
| Loading Height ft (m) | 11.7 (3.6) — Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | 25.8 (41.5) — Starting 2004 Model Year |
| Breakout Force lbs (kgs) | 8,900 (3,960) — Starting 2004 Model Year |
| Digging Depth ft (m) | 14.1 (4.3) — Starting 2004 Model Year |
| SAE Net hp (kW) | 85 (64) — Starting 2004 Model Year |
Backhoe
| Dig Depth | 169 in |
|---|---|
| Reach From Swivel | 217 in |
| Dig Depth - Extended | 215 in |
| Load Height - Extended | 172 in |
| Bucket Dig Force | 11,898 lb |
| Reach From Swivel - Extended | 261 in |
| Load Height | 141 in |
| Bucket Dig Force - Extended | 12,156 lb |
Loader
| Clearance at Max Dump Height | 104 in |
|---|---|
| Bucket Breakout Force | 7,200 lb |
| Bucket Width | 82 in |
| Reach at Max Dump Height | 30 in |
