John DeereJohn Deere
300D
Backhoe Loader
47 specifications
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Operating Weight 4wd | 18,347 lb |
|---|---|
| Operating Weight 2wd | 15,400 lb |
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 24.0 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Tire Size Front - 2wd / 4wd | 12.5/80-18 10PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Alternator Supplied Amperage | 90 A |
| Transmission Fluid Capacity | 4.3 gal |
| Rear Axle Fluid Capacity | 4.8 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 92.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Net Max Torque | 282 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 36.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Tandem Gear |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 98 in |
| Transport Length | 207 in |
| Height to Top of Suspended Cab | 110 in |
Transmission
| Max Speed | 23.9 mph |
|---|---|
| Max Speed - Reverse | 14.0 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 16.9-28 10PR |
|---|
General Specifications
| Operating Weight lbs (kg) | 15,400 (6,985) — Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.1 (4.3) — Starting 2009 Model Year |
| Lift Capacity lbs (kgs) | 7,200 (3,266) — Starting 2007 Model Year |
| Loading Height ft (m) | 11.7 (3.56) — Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | 23.9 (38.4) — Starting 2007 Model Year |
| Backhoe Loading Height ft. (m) | 11.7 (3.6) — Starting 2009 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 23.9 (38.4) — Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 10,301 (4,672) — Starting 2007 Model Year |
| Digging Depth ft (m) | 14.1 (4.3) — Starting 2007 Model Year |
| Loader SAE HP (kw) | 92 (68) — Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 7,200 (3,266) — Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 10,301 (4,672) — Starting 2009 Model Year |
| SAE Net hp (kW) | 92 (68) — Starting 2007 Model Year |
| SAE HP (KW) | 92 (68) — Starting 2010 Model Year |
| Weight lbs (kg) | 15,400 (6,985) — Starting 2010 Model Year |
Backhoe
| Dig Depth | 174 in |
|---|---|
| Reach From Swivel | 222 in |
| Dig Depth - Extended | 216 in |
| Load Height - Extended | 172 in |
| Bucket Dig Force | 11,990 lb |
| Reach From Swivel - Extended | 261 in |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Lift Capacity | 7,200 lb |
| Clearance at Max Dump Height | 107 in |
| Bucket Breakout Force | 11,151 lb |
| Bucket Width | 86 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 6 in |
