John Deere
Case
21F
Wheel Loader
47 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 18,761 lb |
|---|---|
| Fuel Capacity | 42.4 gal |
| Tire Size | 17.5 R25 - Goodyear |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 A |
| Front Axle/Diff Fluid Capacity | 2.5 gal |
| Rear Axle/Diff Fluid Capacity | 2.3 gal |
| Rated Bucket Capacity | 2.00 yd³ |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 270 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 97.0 hp |
| Max Torque | 396 lb-ft |
| Make | Deere |
| Emissions Certification | Interim Tier 4 |
Weights
| Operating Weight | 18,761 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 30.1 gal/min |
|---|---|
| Pump Type | Gear |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 103 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket on Ground | 243 in |
| Hinge Pin - Max Height | 145 in |
Bucket
| Bucket Capacity - heaped | 2.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 113 in |
| Breakout Force | 7,852 lb |
General Specifications
| Operating Weight | 18,761 (8,510) — Starting 2016 Model Year |
|---|---|
| Bucket Capacity | 2.0 (1.5) — Starting 2016 Model Year |
| Engine type | Deere 4045T — Starting 2016 Model Year |
| Engine Power | 97 (72.3) — Starting 2016 Model Year |
| Max Dump Height | 9.4 (2.9) — Starting 2016 Model Year |
