Liebherr
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 11,288 lb |
|---|---|
| Tire Size | 365/70R18 |
| Static Tipping Weight | 7,123 lb |
| Turning Radius | 73 in |
Engine
| Engine Model | D404T |
|---|---|
| Displacement | 149 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 56.4 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 106 in |
| Wheelbase | 85 in |
| Width Over Tires | 71 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket on Ground | 205 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 98 in |
| Bucket Width | 72 in |
