Volvo
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 11,288 lb |
|---|---|
| Fuel Capacity | 22.8 gal |
| Tire Size | 365/80 R20 |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Static Tipping Weight | 8,488 lb |
| Operating Voltage | 12 V |
| Turning Radius | 170 in |
| Engine Oil Fluid Capacity | 2.8 gal |
| Rear Axle Oscillation | 20 ° |
| Alternator Supplied Amperage | 80 A |
| Front Axle/Diff Fluid Capacity | 3.0 gal |
| Rear Axle/Diff Fluid Capacity | 3.2 gal |
Engine
| Engine Model | BF4L 1011F |
|---|---|
| Displacement | 167 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 69.0 hp |
| Net Power | 66.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,800 rpm |
Hydraulic System
| Pump Flow Capacity | 13.8 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.0 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 3,336 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 108 in |
| Wheelbase | 85 in |
| Width Over Tires | 73 in |
| Reach at Max Lift and Dump | 31 in |
| Length with Bucket on Ground | 211 in |
| Hinge Pin - Max Height | 130 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Max Speed - Reverse | 12.5 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.50 yd³ |
|---|---|
| Dump Clearance at Max Raise | 100 in |
| Bucket Width | 76 in |
