Venieri
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 11,354 lb |
|---|---|
| Tire Size | 12.5x20 |
| Static Tipping Weight | 6,394 lb |
| Turning Radius | 89 in |
Engine
| Engine Model | 804C-33 |
|---|---|
| Displacement | 201 in³ |
| Net Power | 60.4 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 109 in |
| Wheelbase | 85 in |
| Width Over Tires | 73 in |
| Reach at Max Lift and Dump | 28 in |
| Length with Bucket on Ground | 199 in |
Transmission
| Max Speed - Forward | 15.6 mph |
|---|---|
| Max Speed - Reverse | 15.6 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 103 in |
| Bucket Width | 76 in |
