Specifications
45 data points
Operating Specifications
| Fuel Capacity | 128.0 gal |
|---|---|
| Tire Size | 26.5R25 |
| Engine Oil Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 8.9 gal |
| Hydraulic System Fluid Capacity | 47.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Transmission Fluid Capacity | 9.0 gal |
Engine
| Engine Model | OM501LA |
|---|---|
| Displacement | 729 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 380.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged w/ charged air cooling |
| Torque Measured @ | 1,080 rpm |
| Max Torque | 1,343 lb-ft |
| Make | Mercedes-Benz |
Weights
| Operating Weight | 133,400 lb |
|---|---|
| Total Empty | 61,730 lb |
| Front Axle - empty | 29,760 lb |
| Total Loaded | 133,380 lb |
| Rear Axle - empty | 15,870 lb |
| Front Axle - loaded | 40,570 lb |
| Rear Axle - loaded | 46,300 lb |
| Center Axle - empty | 16,090 lb |
| Center Axle - loaded | 46,520 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 215 in |
| Overall Length | 404 in |
| Overall Width | 150 in |
| Overall Height | 150 in |
| Dump Height | 282 in |
| Dump Ground Clearance | 32 in |
Transmission
| Max Speed | 34.0 mph |
|---|---|
| Transmission Type | Allison 4500R ORS fully automatic |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Drive System
| Drive Config | 6x6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 71,650 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 13.0 s |
| Lower Time | 7.6 s |
| Capacity - Heaped | 26.30 yd³ |
| Capacity - Struck | 19.89 yd³ |
