John Deere
Ingersoll Rand
BL570
Backhoe Loader
30 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Fuel Capacity | 23.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 19.0 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 F3 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 65 A |
| Turning Radius | 141 in |
| Transmission Fluid Capacity | 3.5 gal |
| Max Weight | 16,000 lb |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 68.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 1,400 rpm |
| Net Max Torque | 170 lb-ft |
Hydraulic System
| Pump Flow Capacity | 23.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,200 psi |
| Pump Type | Close-center |
Dimensions
| Height to Top of Suspended Cab | 104 in |
|---|
Transmission
| Number of Forward Gears | 4 |
|---|---|
| Number of Reverse Gears | 4 |
| Transmission Type | 4-speed with first and second collar shift third and fourth synchronized with hydraulic server |
Tires & Wheels
| Rear Tires Size | 19.5L-24 R4 |
|---|
