John Deere
Tata Hitachi
ZAXIS80LCK
Excavator
33 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 26,184 lb |
|---|---|
| Fuel Capacity | 66.0 gal |
| Hydraulic Pump Flow Capacity | 18.0 gal/min |
| Hydraulic System Fluid Capacity | 19.0 gal |
| Hydraulic System Relief Valve Pressure | 4,050 psi |
| Engine Oil Capacity | 3.8 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.9 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | 300 series |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 100.0 hp |
| Net Power | 95.0 hp |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 284 lb-ft |
Dimensions
| Width to Outside of Tracks | 114 in |
|---|
Swing Mechanism
| Swing Speed | 25 rpm |
|---|
