John Deere
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 4,500 lb |
|---|---|
| Max Speed | 6.7 mph |
| Fuel Capacity | 10.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Cooling System Fluid Capacity | 2.8 gal |
| Chain Box Fluid Capacity - each side | 1.6 gal |
| Operating Speed | 6.7 mph |
Engine
| Engine Model | 3017D001 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 3,000 rpm |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 10.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,650 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 73 in |
| Wheelbase | 39 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 24 in |
| Length with Bucket | 120 in |
| Clearance at Max Lift and Dump | 89 in |
| Turning Radius from Center - inc bucket | 71 in |
| Turning Radius from Center - machine rear | 56 in |
| Length w/o Bucket | 97 in |
Loader
| Operating Load Rating | 1,410 lb |
|---|---|
| Tipping Angle | 2,820 ° |
| Breakout Force | 2,405 psi |
