John Deere
590D
- Operating Weight
- 33,180 lb
- Max Digging Depth
- 239 in
- Max Digging Depth
- 258 in
- Net Power
- 95.0 hp
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 33,180 lb |
|---|---|
| Fuel Capacity | 66.0 gal |
| Hydraulic Pump Flow Capacity | 41.7 gal/min |
| Hydraulic System Fluid Capacity | 42.3 gal |
| Hydraulic System Relief Valve Pressure | 5,050 psi |
| Engine Oil Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 22.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.3 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | e 4276T |
|---|---|
| Displacement | 276 in³ |
| Gross Power | 100.0 hp |
| Net Power | 95.0 hp |
| Aspiration | Turbocharged |
| Max Torque | 284 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 110 in |
| Length of Track on Ground | 114 in |
| Tail Swing Radius | 96 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 40 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 84 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.9 mph |
| Shoe Size | 20 in |
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 22,500 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 239 in |
|---|---|
| Max Reach Along Ground | 344 in |
| Max Loading Height | 228 in |
| Max Vertical Wall Digging Depth | 205 in |
| Max Cutting Height | 337 in |
| Shipping Length of Unit | 336 in |
| Shipping Height of Unit | 110 in |
Bucket
| Reference Bucket Capacity | 0.90 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.10 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 258 in |
|---|---|
| Max Vertical Wall Digging Depth | 226 in |
| Max Cutting Height | 347 in |
| Max Loading Height | 238 in |
| Max Reach Along Ground | 362 in |
| Shipping Length of Unit | 336 in |
| Shipping Height of Unit | 119 in |
