John Deere
Champion
730A
Motor Grader
53 specifications
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Max Operation Weight - Total | 35,230 lb |
|---|---|
| Max Operation Weight - Front Axle | 9,760 lb |
| Max Operation Weight - Rear Axle | 25,470 lb |
| Std Operation Weight - Total | 30,500 lb |
| Tire Size | 13.00-24 |
| Fuel Capacity | 106.0 gal |
| Std Operation Weight - Front Axle | 8,640 lb |
| Std Operation Weight - Rear Axle | 21,860 lb |
| Hydraulic System Fluid Capacity | 15.5 gal |
| Tandem Case Fluid Capacity (each) | 20.0 gal |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 11.0 gal |
| Alternator Supplied Amperage | 55 A |
| Transmission Fluid Capacity | 10.0 gal |
| Circle Gearbox Fluid Capacity | 4.0 gal |
| Rear Diff/Final Drive Fluid Capacity | 9.5 gal |
| Oil System Fluid Capacity | 6.4 gal |
Engine
| Engine Model | 6068H |
|---|---|
| Displacement | 414 in³ |
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged with Aftercooler |
| Torque Measured @ | 1,000 rpm |
| Max Power | 140.0 hp |
| Net Power Gears 7-8 | 140.0 hp |
| Net Torque Gears 7-8 | 496 lb-ft |
Hydraulic System
| Pump Flow | 45.6 gal/min |
|---|---|
| Pump Type | Closed center variavle displacement |
| Relief Valve Pressure | 2,550 psi |
Dimensions
| Wheelbase | 235 in |
|---|---|
| Overall Length | 339 in |
| Width Over Tires | 98 in |
| Height to Top of Isomount Cab | 122 in |
| Blade Base | 106 in |
| Tandem Axle Wheelbase | 61 in |
| Front Ground Clearance | 25 in |
Transmission
| Max Speed - Forward | 25.0 mph |
|---|---|
| Max Speed - Reverse | 25.0 mph |
| Number of Gears - Forward | 8 |
| Number of Gears - Reverse | 8 |
| Transmission Type | Power Shift |
Moldboard
| Moldboard Height | 24 in |
|---|---|
| Moldboard Width | 144 in |
| Moldboard Thickness | 1 in |
| Side Shift Left | 27 in |
| Side Shift Right | 27 in |
| Blade Pull at Max Weight | 24,248 lb |
Circle
| Max Lift Above Ground | 18 in |
|---|---|
| Max Reach Outside Tires - Left | 85 in |
| Max Reach Outside Tires - Right | 83 in |
| Diameter | 60 in |
| Blade Tip Angle - Front | 49 ° |
| Rotation | 360 ° |
| Blade Tip Angle - Rear | 5 ° |
| Shift Left | 31 in |
| Shift Right | 29 in |
Front Axle
| Wheel Lean | 20 ° |
|---|---|
| Oscillation - Total | 32 ° |
| Ground Clearance | 288 in |
Steering System
| Turning Radius | 264 in |
|---|---|
| Articulation Angle | 25 ° |
