John Deere
Caterpillar
120G
Motor Grader
17 specifications
1 / 5
Image 1 of 5
Specifications
11 data points
Operating Specifications
| Operating Weight | 33,820 lb |
|---|
Engine
| Base Power (1st Gear) - Net | 155.0 hp |
|---|
Moldboard
| Moldboard Height | 24 in |
|---|---|
| Moldboard Length | 144 in |
Blades
| Maximum Shoulder Reach Outside of Tires - Left | 7 in |
|---|---|
| Maximum Shoulder Reach Outside of Tires - Right | 7 in |
| Moldboard Sideshift - Left | 27 in |
| Moldboard Sideshift - Right | 27 in |
Circle
| Max Lift Above Ground | 19 in |
|---|
Steering System
| Turning Radius | 284 in |
|---|---|
| Articulation Angle | 22 ° |
Comparable machines
Other motor graders in a similar weight class.
