John Deere
New Holland
MH2.6
Excavator
45 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 36,100 lb |
|---|---|
| Fuel Capacity | 60.0 gal |
| Hydraulic Pump Flow Capacity | 84.0 gal/min |
| Hydraulic System Fluid Capacity | 80.0 gal |
| Hydraulic System Relief Valve Pressure | 2,500 psi |
| Engine Oil Capacity | 15.0 gal |
| Cooling System Fluid Capacity | 11.3 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 7.5 gal |
Engine
| Displacement | 404 in³ |
|---|---|
| Power Measured @ | 2,400 rpm |
| Gross Power | 141.0 hp |
| Net Power | 131.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 345 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 118 in |
| Tail Swing Radius | 102 in |
| Width to Outside of Tracks | 96 in |
| Removal Counterweight Clearance | 37 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Max Travel Speed | 1.2 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 252 in |
|---|---|
| Max Reach Along Ground | 360 in |
| Max Loading Height | 180 in |
| Max Cutting Height | 264 in |
| Shipping Length of Unit | 354 in |
| Shipping Height of Unit | 131 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.90 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 7 rpm |
|---|
