John Deere
Caterpillar
311C U
Excavator
21 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 43,890 lb |
|---|---|
| Fuel Capacity | 85.0 gal |
| Hydraulic Pump Flow Capacity | 100.0 gal/min |
| Hydraulic System Fluid Capacity | 84.0 gal |
| Hydraulic System Relief Valve Pressure | 5,000 psi |
| Engine Oil Capacity | 20.0 gal |
| Cooling System Fluid Capacity | 44.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 4.0 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | e 6068T |
|---|---|
| Displacement | 414 in³ |
| Gross Power | 140.0 hp |
| Net Power | 130.0 hp |
| Max Torque | 424 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 113 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 104 in |
| Width to Outside of Tracks | 120 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.9 mph |
| Shoe Size | 26 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 40,300 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 449 in |
|---|---|
| Max Reach Along Ground | 600 in |
| Max Loading Height | 465 in |
| Max Cutting Height | 536 in |
| Shipping Length of Unit | 468 in |
| Shipping Height of Unit | 128 in |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
