570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 45,418 lb |
|---|---|
| Max Speed | 3.0 mph |
| Fuel Capacity | 154.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic System Fluid Capacity | 52.1 gal |
| Cooling System Fluid Capacity | 10.2 gal |
| Engine Oil Capacity | 7.4 gal |
Engine
| Engine Model | 6081H |
|---|---|
| Displacement | 494 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 181.1 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 679 lb-ft |
Dimensions
| Height - Top of Cab | 134 in |
|---|---|
| Overall Width | 117 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 91 in |
| Number of Track Rollers per Side | 8 |
| Shoe Size | 24 in |
| Track Pitch | 8 in |
| Ground Clearance | 29 in |
| Track Length | 163 in |
Boom
| Max Reach w/ Head | 391 in |
|---|
