John Deere
Caterpillar
633E II
Scraper
91 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Fuel Capacity | 72.0 gal |
|---|---|
| Cooling System Fluid Capacity | 9.1 gal |
| Transmission Fluid Capacity | 13.0 gal |
| Engine Oil Fluid Capacity | 4.8 gal |
| Hydraulic System Fluid Capacity | 3.4 gal |
| Differential Fluid Capacity | 5.8 gal |
Dimensions
| Height - Top of Cab | 119 in |
|---|---|
| Wheelbase | 252 in |
| Overall Length | 395 in |
| Overall Width | 97 in |
| Tractor Ground Clearance | 18 in |
Transmission
| Number of Forward Gears | 6 |
|---|---|
| Number of Reverse Gears | 1 |
Tractor Engine
| Net Power | 190.0 hp |
|---|---|
| Gross Power | 175.0 hp |
| Displacement | 619 in³ |
| Make | John Deere |
| Power Measured @ | 2,100 rpm |
