633E II
Scraper
91 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Fuel Capacity | 72.2 gal |
|---|---|
| Cooling System Fluid Capacity | 9.0 gal |
| Transmission Fluid Capacity | 13.0 gal |
| Engine Oil Fluid Capacity | 6.3 gal |
| Hydraulic System Fluid Capacity | 12.0 gal |
Dimensions
| Height - Top of Cab | 119 in |
|---|---|
| Wheelbase | 252 in |
| Overall Length | 395 in |
| Overall Width | 97 in |
| Tractor Ground Clearance | 18 in |
Transmission
| Max Speed - Forward | 45.5 mph |
|---|---|
| Max Speed - Reverse | 8.0 mph |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Bowl
| Heaped Capacity | 11.00 yd³ |
|---|---|
| Rated Payload | 27,500 lb |
Tractor Engine
| Net Power | 180.0 hp |
|---|---|
| Displacement | 466 in³ |
| Make | John Deere |
| Power Measured @ | 2,100 rpm |
