John Deere
Volvo
L90C
Wheel Loader
44 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 59,084 lb |
|---|---|
| Fuel Capacity | 126.1 gal |
| Front Axle/Diff Fluid Capacity | 14.7 gal |
| Rear Axle/Diff Fluid Capacity | 14.7 gal |
| Rated Bucket Capacity | 6.00 yd³ |
Engine
| Engine Model | PowerTech PSS 6135 |
|---|---|
| Displacement | 824 in³ |
| Net Power | 333.0 hp |
| Engine Make | John Deere |
| Make | Deere PowerTech |
| Torque Rise | 57.0 % |
| Torque | 1,206 lb-ft |
| Alternator | 130 A |
| System Voltage | 24 V |
| Rated Speed | 1,500 rpm |
| Transmission Type | Powershift |
| Emission level | Tier 4 |
| Engine Output-Net | 332.6 hp |
| Pump | Piston |
Weights
| Operating Weight | 59,260 lb |
|---|
Dimensions
| Height - Top of Cab | 141 in |
|---|---|
| Wheelbase | 137 in |
| Width Over Tires | 122 in |
| Reach at Max Lift and Dump | 81 in |
| Length with Bucket on Ground | 366 in |
| Hinge Pin - Max Height | 176 in |
| Turning Circle | 565 in |
Transmission
| Pump Flow | 129.8 gal/min |
|---|---|
| System Pressure | 252 psi |
Fluid Capacities
| Hydraulic Tank | 43.6 gal |
|---|---|
| Transmission | 7.4 gal |
| Heaped Capacity | 6.10 yd³ |
Bucket
| Bucket Capacity - Smallest | 6.10 yd³ |
|---|---|
| Breakout Force | 41,266 lb |
| Largest bucket capacity | 6.91 yd³ |
Driveline
| Ride control system | Yes |
|---|---|
| Parking Brake Type | Wet Multi Disc |
| Service Brake - Location | All Wheels |
| Service Brake Actuation | Hydraulic |
| Service Brake Type | Wet Disc |
| Tire size - Standard | 26.5 R25 |
| Differential lock | Front- Locking Rear- Open |
