John Deere
Caterpillar
633E II
Scraper
91 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Fuel Capacity | 90.1 gal |
|---|---|
| Cooling System Fluid Capacity | 11.5 gal |
| Transmission Fluid Capacity | 12.0 gal |
| Engine Oil Fluid Capacity | 8.6 gal |
| Hydraulic System Fluid Capacity | 25.0 gal |
| Operating Voltage | 24 V |
| Differential Fluid Capacity | 15.1 gal |
Dimensions
| Height - Top of Cab | 132 in |
|---|---|
| Wheelbase | 274 in |
| Overall Length | 431 in |
| Overall Width | 115 in |
| Tractor Ground Clearance | 17 in |
Transmission
| Number of Forward Gears | 5 |
|---|---|
| Number of Reverse Gears | 1 |
Bowl
| Heaped Capacity | 15.09 yd³ |
|---|---|
| Rated Payload | 37,501 lb |
Tractor Engine
| Net Power | 225.0 hp |
|---|---|
| Gross Power | 240.0 hp |
| Displacement | 619 in³ |
| Make | John Deere |
| Power Measured @ | 2,100 rpm |
Comparable machines
Other scrapers in a similar weight class.
