John Deere
Caterpillar
633E II
Scraper
91 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Fuel Capacity | 109.9 gal |
|---|---|
| Cooling System Fluid Capacity | 13.0 gal |
| Transmission Fluid Capacity | 18.8 gal |
| Engine Oil Fluid Capacity | 9.0 gal |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Operating Voltage | 12 V |
Dimensions
| Overall Length | 44 in |
|---|
Transmission
| Max Speed - Forward | 45.9 mph |
|---|---|
| Max Speed - Reverse | 8.0 mph |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Bowl
| Heaped Capacity | 16.00 yd³ |
|---|---|
| Rated Payload | 40,001 lb |
Tractor Engine
| Net Power | 265.0 hp |
|---|---|
| Displacement | 619 in³ |
| Make | John Deere |
| Power Measured @ | 2,100 rpm |
Comparable machines
Other scrapers in a similar weight class.
