John Deere
Hyundai
HSL215T
Skid Steer Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 2,825 lb |
|---|---|
| Max Speed | 5.0 mph |
| Fuel Capacity | 7.2 gal |
| Hydraulic System Fluid Capacity | 11.0 gal |
| Tire Size | 8.50-15 |
| Operating Voltage | 12 V |
| Operating Speed | 5.0 mph |
Engine
| Displacement | 60 in³ |
|---|---|
| Power Measured @ | 3,000 rpm |
| Gross Power | 23.0 hp |
| Number of Cylinders | 2 |
Hydraulic System
| Pump Flow Capacity | 7.5 gal/min |
|---|---|
| Relief Valve Pressure | 1,750 psi |
| Pump Type | Open-center |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 74 in |
| Wheelbase | 31 in |
| Width Over Tires | 46 in |
| Reach at Max Lift and Dump | 125 in |
| Length with Bucket | 103 in |
| Clearance at Max Lift and Dump | 73 in |
| Turning Radius from Center - inc bucket | 47 in |
| Turning Radius from Center - machine rear | 47 in |
| Length w/o Bucket | 80 in |
Loader
| Bucket Capacity | 0.41 yd³ |
|---|---|
| Operating Load Rating | 700 lb |
| Tipping Angle | 1,400 ° |
