John Deere
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 4,750 lb |
|---|---|
| Max Speed | 7.0 mph |
| Fuel Capacity | 25.0 gal |
| Hydraulic System Fluid Capacity | 20.0 gal |
| Tire Size | 10.00-16.56-ply rating R3 |
| Operating Voltage | 12 V |
| Engine Oil Fluid Capacity | 1.3 gal |
| Operating Speed | 7.0 mph |
Engine
| Engine Model | Wisconsin VG4D |
|---|---|
| Displacement | 154 in³ |
| Gross Power | 37.0 hp |
| Aspiration | 4-cylinder 4-stroke cycle |
Hydraulic System
| Pump Flow Capacity | 18.0 gal/min |
|---|---|
| Relief Valve Pressure | 1,750 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Wheelbase | 36 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 3 in |
| Length with Bucket | 124 in |
| Clearance at Max Lift and Dump | 108 in |
| Turning Radius from Center - inc bucket | 5 in |
| Turning Radius from Center - machine rear | 5 in |
| Length w/o Bucket | 90 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 1,700 lb |
