JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 46,000 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 124.2 gal/min |
| Hydraulic System Relief Valve Pressure | 4,641 psi |
Engine
| Engine Model | Cummins 6A5 9-C |
|---|---|
| Net Power | 169.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 109 in |
| Length of Track on Ground | 148 in |
| Tail Swing Radius | 117 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 95 in |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 278 in |
|---|---|
| Max Reach Along Ground | 410 in |
| Max Loading Height | 282 in |
| Max Cutting Height | 380 in |
| Shipping Length of Unit | 388 in |
| Shipping Height of Unit | 134 in |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
