Kato
CR250
- Operating Weight
- 52,911 lb
- Max Lift Capacity
- 55,116 lb
- Max Speed - Forward
- 30.5 mph
- Displacement
- 461 in³
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 52,911 lb |
|---|---|
| Operating Voltage | 24 V |
| Tire Size | 385/95R25 170E ROAD |
| Carrier Fuel Capacity | 79.3 gal |
| Upper Structure Hydraulic System Fluid Capacity | 116.3 gal |
| Number of Axels | 2 |
| Alternator Supplied Amperage | 40 A |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Transport Width | 95 in |
| Transport Height | 134 in |
| Transport Length | 357 in |
| Width w/ Outriggers Extended | 248 in |
| Upper Structure Tail Swing Radius | 95 in |
| Carrier Length | 285 in |
Transmission
| Max Speed - Forward | 30.5 mph |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
| Transmission Type | remote mounted full automatic with transfer gear box |
Boom
| Max Lift Capacity | 55,116 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,222 in |
| Min Height @ Max Raise Angle | 316 in |
| Max Elevating Angle | 81 ° |
| Number of Sections | 6 |
| Swing Speed | 3 rpm |
| Min Working Radius | 110 in |
| Max Working Radius | 1,025 in |
CARRIER ENGINE
| Gross Power | 211.9 hp |
|---|---|
| Displacement | 461 in³ |
| Power Measured @ | 2,800 rpm |
| Make | Kato |
| Max Torque | 513 lb-ft |
| Torque Measured @ | 1,600 rpm |
