Kato
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 31,967 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 90.9 gal/min |
| Hydraulic System Fluid Capacity | 59.5 gal |
| Hydraulic System Relief Valve Pressure | 4,760 psi |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 30 A |
Engine
| Engine Model | C 6D31T |
|---|---|
| Displacement | 302 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 99.3 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 281 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 109 in |
| Length of Track on Ground | 113 in |
| Tail Swing Radius | 98 in |
| Width to Outside of Tracks | 98 in |
| Removal Counterweight Clearance | 39 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 20 in |
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 33,700 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 217 in |
|---|---|
| Max Reach Along Ground | 325 in |
| Max Loading Height | 233 in |
| Max Vertical Wall Digging Depth | 181 in |
| Max Cutting Height | 333 in |
Bucket
| Reference Bucket Capacity | 0.90 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.99 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 239 in |
|---|---|
| Max Vertical Wall Digging Depth | 207 in |
| Max Cutting Height | 343 in |
| Max Loading Height | 243 in |
| Max Reach Along Ground | 346 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 258 in |
|---|---|
| Max Cutting Height | 352 in |
| Max Loading Height | 251 in |
| Max Vertical Wall Digging Depth | 226 in |
| Max Reach Along Ground | 364 in |
