Kato
HD700V II LC
- Operating Weight
- 41,888 lb
- Max Digging Depth
- 241 in
- Max Digging Depth
- 261 in
- Net Power
- 123.4 hp
1 / 5
Image 1 of 5
Specifications
51 data points
Operating Specifications
| Operating Weight | 41,888 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Hydraulic Pump Flow Capacity | 121.6 gal/min |
| Hydraulic System Fluid Capacity | 74.0 gal |
| Hydraulic System Relief Valve Pressure | 4,760 psi |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 30 A |
Engine
| Engine Model | 6D31T |
|---|---|
| Displacement | 302 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 123.4 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,700 rpm |
| Max Torque | 318 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 115 in |
| Tail Swing Radius | 110 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 52 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 39,000 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 241 in |
|---|---|
| Max Reach Along Ground | 370 in |
| Max Loading Height | 265 in |
| Max Vertical Wall Digging Depth | 221 in |
| Max Cutting Height | 380 in |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 261 in |
|---|---|
| Max Vertical Wall Digging Depth | 241 in |
| Max Cutting Height | 385 in |
| Max Loading Height | 272 in |
| Max Reach Along Ground | 388 in |
| Shipping Length of Unit | 377 in |
| Shipping Height of Unit | 115 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 301 in |
|---|---|
| Max Cutting Height | 404 in |
| Max Loading Height | 289 in |
| Max Vertical Wall Digging Depth | 280 in |
| Max Reach Along Ground | 425 in |
