Kato
KR500
- Operating Weight
- 81,571 lb
- Max Lift Capacity
- 110,231 lb
- Max Speed - Forward
- 33.0 mph
- Gross Power
- 266.9 hp
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 81,571 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 18.00-25-28PR |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 148.0 gal |
Engine
| Engine Model | 6D22T |
|---|---|
| Displacement | 680 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 266.9 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 759 lb-ft |
Dimensions
| Wheelbase | 14 in |
|---|---|
| Transport Width | 119 in |
| Transport Height | 149 in |
| Transport Length | 469 in |
| Width w/ Outriggers Extended | 288 in |
| Upper Structure Tail Swing Radius | 131 in |
| Carrier/Base Length | 335 in |
Transmission
| Max Speed - Forward | 33.0 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | remote mounted full powershift |
Boom
| Max Lift Capacity | 110,231 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,496 in |
| Min Height @ Max Raise Angle | 531 in |
| Max Elevating Angle | 82 ° |
| Number of Sections | 5 |
| Swing Speed | 3 rpm |
| Min Operating Radius | 119 in |
| Max Operating Radius | 1,222 in |
