Kawasaki

65ZV-2

Wheel Loader

Operating Weight
25,574 lb
Bucket Capacity - heaped
3.10 yd³
Gross Power
154.0 hp
Net Power
149.0 hp
All wheel loaders
Kawasaki 65ZV-2 Wheel Loader
1 / 5
Image 1 of 5
Image: machineryline.info

Specifications

45 data points

Operating Specifications

Operating Specifications specifications
Operating Weight25,574 lb
Fuel Capacity55.5 gal
Tire Size20.5-25-12PR
Hydraulic System Fluid Capacity19.9 gal
Static Tipping Weight22,950 lb
Operating Voltage24 V
Turning Radius228 in
Engine Oil Fluid Capacity4.0 gal
Rear Axle Oscillation24 °
Alternator Supplied Amperage50 A
Front Axle/Diff Fluid Capacity6.7 gal
Rear Axle/Diff Fluid Capacity6.7 gal
Cooling System Fluid Capacity8.0 gal
Transmission Fluid Capacity6.7 gal
Rated Bucket Capacity3.00 yd³

Engine

Engine specifications
Engine Model4HKIX
Displacement317 in³
Power Measured @2,200 rpm
Gross Power154.0 hp
Net Power149.0 hp
Number of Cylinders4
AspirationTurbocharger with Intercooler
Torque Measured @1,500 rpm
MakeIsuzu

Weights

Weights specifications
Operating Weight25,580 lb

Hydraulic System

Hydraulic System specifications
Raise Time5.8 s
Lower Time2.9 s
Dump Time1.2 s
Relief Valve Setting3,000 psi

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab130 in
Wheelbase115 in
Width Over Tires95 in
Reach at Max Lift and Dump40 in
Length with Bucket on Ground283 in
Hinge Pin - Max Height149 in

Transmission

Transmission specifications
Max Speed - Forward22.3 mph
Max Speed - Reverse22.3 mph
Transmission TypePower shift
Number of Forward Gears4
Number of Reverse Gears4

Bucket

Bucket specifications
Bucket Capacity - heaped3.10 yd³
Bucket Capacity - struck2.69 yd³
Dump Clearance at Max Raise111 in
Bucket Width101 in
