Kobelco
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 31,750 lb |
|---|---|
| Fuel Capacity | 44.4 gal |
| Hydraulic Pump Flow Capacity | 81.4 gal/min |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 3.4 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Swing Drive Fluid Capacity | 0.5 gal |
Engine
| Engine Model | A-4BG1T |
|---|---|
| Displacement | 264 in³ |
| Power Measured @ | 2,050 rpm |
| Net Power | 84.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 108 in |
| Length of Track on Ground | 114 in |
| Tail Swing Radius | 56 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 79 in |
| Max Travel Speed | 3.7 mph |
| Shoe Size | 24 in |
| Drawbar Pull | 28,500 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 324 in |
| Max Loading Height | 245 in |
| Max Vertical Wall Digging Depth | 196 in |
| Max Cutting Height | 341 in |
| Shipping Length of Unit | 311 in |
| Shipping Height of Unit | 111 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.10 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
