Kobelco
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 60,640 lb |
|---|---|
| Fuel Capacity | 77.0 gal |
| Hydraulic Pump Flow Capacity | 105.7 gal/min |
| Hydraulic System Fluid Capacity | 61.0 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
Engine
| Engine Model | 6D34-TE1 |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 143.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 152 in |
| Tail Swing Radius | 72 in |
| Width to Outside of Tracks | 137 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 102 in |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 32 in |
| Drawbar Pull | 52,920 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 245 in |
|---|---|
| Max Reach Along Ground | 378 in |
| Max Loading Height | 348 in |
| Max Vertical Wall Digging Depth | 224 in |
| Max Cutting Height | 461 in |
| Shipping Length of Unit | 350 in |
| Shipping Height of Unit | 125 in |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.70 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
