Kobelco
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 7,100 lb |
|---|---|
| Fuel Capacity | 10.0 gal |
| Hydraulic Pump Flow Capacity | 22.6 gal/min |
| Hydraulic System Fluid Capacity | 12.7 gal |
| Hydraulic System Relief Valve Pressure | 3,336 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | 3TNV88-PYB |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 28.4 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 102 in |
| Length of Track on Ground | 79 in |
| Tail Swing Radius | 31 in |
| Width to Outside of Tracks | 61 in |
| Removal Counterweight Clearance | 23 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 50 in |
| Max Travel Speed | 2.8 mph |
| Shoe Size | 12 in |
| Drawbar Pull | 8,663 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 111 in |
|---|---|
| Max Reach Along Ground | 189 in |
| Max Vertical Wall Digging Depth | 85 in |
| Max Loading Height | 133 in |
| Shipping Length of Unit | 174 in |
| Max Cutting Height | 189 in |
| Shipping Height of Unit | 102 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 752 lb-ft |
