Kobelco
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 43,700 lb |
|---|---|
| Fuel Capacity | 74.3 gal |
| Hydraulic Pump Flow Capacity | 96.7 gal/min |
| Hydraulic System Fluid Capacity | 42.1 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 5.1 gal |
Engine
| Engine Model | C 4D34-TEG |
|---|---|
| Displacement | 238 in³ |
| Net Power | 112.0 hp |
| Aspiration | Turbocharged diesel |
| Max Torque | 283 lb-ft |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 118 in |
| Tail Swing Radius | 100 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 43 in |
| Digging Depth | 257 in |
| Digging Reach | 257 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 79 in |
| Max Travel Speed | 3.8 mph |
| Shoe Size | 24 in |
| Drawbar Pull | 21,832 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 257 in |
|---|---|
| Max Reach Along Ground | 369 in |
| Max Loading Height | 276 in |
| Max Vertical Wall Digging Depth | 235 in |
| Max Cutting Height | 381 in |
| Shipping Length of Unit | 341 in |
| Shipping Height of Unit | 121 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.40 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Comparable machines
Other excavators in a similar weight class.
