Kobelco
Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 58,411 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 445/95R25 177E |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 97.8 gal |
Engine
| Engine Model | 6D16TUA |
|---|---|
| Displacement | 461 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 211.9 hp |
| Torque Measured @ | 1,250 rpm |
| Max Torque | 521 lb-ft |
| Engine Make | Mitsubishi |
Dimensions
| Wheelbase | 146 in |
|---|---|
| Transport Width | 98 in |
| Transport Height | 137 in |
| Transport Length | 434 in |
| Width w/ Outriggers Extended | 248 in |
| Upper Structure Tail Swing Radius | 120 in |
Transmission
| Max Speed - Forward | 31.1 mph |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 1 |
Boom
| Max Height @ Max Raise Angle - no jib | 1,205 in |
|---|---|
| Min Height @ Max Raise Angle | 367 in |
| Max Elevating Angle | 82 ° |
| Number of Sections | 4 |
| Swing Speed | 3 rpm |
