Kobelco
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 44,974 lb |
|---|---|
| Fuel Capacity | 89.9 gal |
| Hydraulic Pump Flow Capacity | 111.0 gal/min |
| Hydraulic System Fluid Capacity | 65.0 gal |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 5.1 gal |
| Swing Drive Fluid Capacity | 2.0 gal |
Engine
| Engine Model | 6D34-TLE2A |
|---|---|
| Displacement | 358 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 148.0 hp |
| Net Power | 147.6 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 428 lb-ft |
| Engine Make | Mitsubishi |
| Bore | 4 in |
| Stroke | 5 in |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 371 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 119 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Max Travel Speed | 3.8 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Drawbar Pull | 44,737 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 264 in |
|---|---|
| Max Reach Along Ground | 384 in |
| Max Loading Height | 268 in |
| Max Vertical Wall Digging Depth | 239 in |
| Max Cutting Height | 378 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
