Kobelco
JCB
JS240L
Excavator
13 specifications
Kobelco
SK250 LC
- Operating Weight
- 55,402 lb
- Max Digging Depth
- 277 in
- Max Digging Depth
- 305 in
- Net Power
- 176.0 hp
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 55,402 lb |
|---|---|
| Fuel Capacity | 89.9 gal |
| Hydraulic Pump Flow Capacity | 132.4 gal/min |
| Hydraulic System Fluid Capacity | 68.7 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 5.9 gal |
Engine
| Engine Model | 6D34-TLEG |
|---|---|
| Displacement | 358 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 176.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 152 in |
| Tail Swing Radius | 118 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 102 in |
| Max Travel Speed | 3.8 mph |
| Shoe Size | 32 in |
| Drawbar Pull | 51,500 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 277 in |
|---|---|
| Max Reach Along Ground | 400 in |
| Max Loading Height | 270 in |
| Max Vertical Wall Digging Depth | 245 in |
| Max Cutting Height | 385 in |
| Shipping Length of Unit | 397 in |
| Shipping Height of Unit | 121 in |
Bucket
| Reference Bucket Capacity | 1.40 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.30 yd³ |
| Minimum Bucket Capacity | 0.90 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 305 in |
|---|---|
| Max Vertical Wall Digging Depth | 276 in |
| Max Cutting Height | 401 in |
| Max Loading Height | 284 in |
| Max Reach Along Ground | 426 in |
| Shipping Length of Unit | 397 in |
| Shipping Height of Unit | 125 in |
