PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 5,644 lb |
|---|---|
| Fuel Capacity | 8.1 gal |
Engine
| Engine Model | YANMAR 3TNV80F-SXNBV |
|---|---|
| Displacement | 77 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 19.7 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 47 lb-ft |
| Engine Type | Tier4 water-cooled 4-cycle 3-cylinder |
Hydraulic System
| Pump Type | Two variable displacement pumps + two gear pump |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 101 in |
| Length of Track on Ground | 163 in |
| Tail Swing Radius | 31 in |
| Width to Outside of Tracks | 50 in |
| Traction force | 5,485 lb |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 3 |
| Max Travel Speed | 2.8 mph |
| Shoe Size | 10 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 110 in |
|---|---|
| Max Reach Along Ground | 183 in |
| Max Vertical Wall Digging Depth | 98 in |
| Max Loading Height | 117 in |
| Shipping Length of Unit | 163 in |
| Max Cutting Height | 170 in |
| Shipping Height of Unit | 101 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
