Kobelco
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 6,614 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 26.5 gal/min |
| Hydraulic System Relief Valve Pressure | 3,336 psi |
Engine
| Engine Model | 3TNV88 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 28.5 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Length of Track on Ground | 61 in |
| Tail Swing Radius | 31 in |
| Width to Outside of Tracks | 61 in |
Undercarriage
| Max Travel Speed | 2.8 mph |
|---|---|
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 111 in |
|---|---|
| Max Reach Along Ground | 189 in |
| Max Vertical Wall Digging Depth | 85 in |
| Max Loading Height | 111 in |
| Shipping Length of Unit | 174 in |
| Shipping Height of Unit | 102 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|
