Kobelco
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,320 lb |
|---|---|
| Fuel Capacity | 11.1 gal |
Engine
| Engine Model | YANMAR 3TNV88F-E |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 23.0 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,440 rpm |
| Max Torque | 60 lb-ft |
| Engine Type | Water cooled 4-cycle 3-cylinder direct injection diesel engine |
Hydraulic System
| Pump Type | Two variable displacement pumps + one gear pump |
|---|
Dimensions
| Height - Top of Cab | 100 in |
|---|---|
| Length of Track on Ground | 187 in |
| Tail Swing Radius | 32 in |
| Width to Outside of Tracks | 61 in |
| Traction force | 8,630 lb |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 111 in |
|---|---|
| Max Reach Along Ground | 199 in |
| Max Vertical Wall Digging Depth | 95 in |
| Max Loading Height | 135 in |
| Shipping Length of Unit | 187 in |
| Max Cutting Height | 191 in |
| Shipping Height of Unit | 100 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
