Kobelco
Komatsu
PC20R-8
Mini Excavator
47 specifications
:quality(50)/60781/d178d19c-888a-4135-b683-10deebf75b9b.png)
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 7,893 lb |
|---|---|
| Hydraulic System Fluid Capacity | 12.7 gal |
| Travel speed, high range | 1.6 mph |
| Travel speed, low range | 2.8 mph |
Engine
| Power Measured @ | 2,400 rpm |
|---|---|
| Net Power | 28.5 hp |
| Number of Cylinders | 3 |
| Max Torque | 72 lb-ft |
Hydraulic System
| Pump Type | Two variable displacement pumps |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 102 in |
| Wheelbase | 67 in |
| Length of Track on Ground | 67 in |
| Tail Swing Radius | 33 in |
| Width to Outside of Tracks | 67 in |
Undercarriage
| Max Travel Speed | 2.8 mph |
|---|---|
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 122 in |
|---|---|
| Max Reach Along Ground | 202 in |
| Max Vertical Wall Digging Depth | 95 in |
| Max Loading Height | 142 in |
| Shipping Length of Unit | 186 in |
| Shipping Height of Unit | 102 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
