G66
Motor Grader
32 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Std Operation Weight - Total | 19,687 lb |
|---|---|
| Tire Size | front 9.00-20-10PR rear 11.00-20-10PR |
| Std Operation Weight - Front Axle | 5,269 lb |
| Std Operation Weight - Rear Axle | 14,418 lb |
Engine
| Engine Model | 4D130 |
|---|---|
| Displacement | 518 in³ |
| Max Power | 110.0 hp |
| Net Power Gear 5-6 | 110.0 hp |
| Net Torque Gears 5-6 | 375 lb-ft |
Dimensions
| Wheelbase | 193 in |
|---|---|
| Overall Length | 267 in |
| Width Over Tires | 83 in |
| Height to Top of Isomount Cab | 125 in |
| Tandem Axle Wheelbase | 48 in |
| Front Ground Clearance | 18 in |
| Rear Ground Clearance | 15 in |
Transmission
| Max Speed - Forward | 23.8 mph |
|---|---|
| Max Speed - Reverse | 7.3 mph |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 2 |
| Transmission Type | sliding mesh and constant mesh combined |
Moldboard
| Moldboard Height | 21 in |
|---|---|
| Moldboard Width | 122 in |
| Moldboard Thickness | 1 in |
| Max Depth of Cut | 17 in |
Circle
| Max Lift Above Ground | 18 in |
|---|---|
| Max Reach Outside Tires - Left | 61 in |
| Max Reach Outside Tires - Right | 61 in |
Front Axle
| Wheel Lean | 25 ° |
|---|---|
| Oscillation - Total | 26 ° |
| Ground Clearance | 18 in |
Steering System
| Turning Radius | 355 in |
|---|
