Komatsu
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 46,782 lb |
|---|---|
| Fuel Capacity | 105.7 gal |
| Hydraulic System Fluid Capacity | 35.7 gal |
| Cooling System Fluid Capacity | 4.6 gal |
| Swing Drive Fluid Capacity | 1.9 gal |
Engine
| Engine Model | SAA4D107E-2-A |
|---|---|
| Displacement | 272 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 148.0 hp |
| Net Power | 139.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 120 in |
| Width to Outside of Tracks | 118 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Number of Track Rollers per Side | 9 |
|---|---|
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
